Retina 800
Plug and play automated fundus camera for retinal screening in any practice
- Fully automatic capture Auto focus and auto shoot, no manual alignment needed
- 45° true colour 5 MP images, with mosaic imaging up to 90° horizontal
- Small pupil capable Images through pupils down to 2.5 mm without dilation
- Space saving design Compact footprint with a 10.43-inch tablet interface
Overview
Retina 800 is a fully automated, non-mydriatic fundus camera that brings retinal screening into any optometry practice. Auto focus and auto capture take 45° colour images in a few seconds at the press of a button, with no mechanical adjustment by the operator. A compact footprint and a tablet interface let the practice place it wherever it suits the workflow. Minimal operator training is needed, so retinal photos can be delegated to support staff while the practitioner reviews the results.
Image quality at your fingertips
- Clear, true colour: vessels, arteries, veins, crossing vessels, the retinal nerve fibre layer and the optic disc are captured in true colour.
- Small pupils: images down to a 2.5 mm pupil, even in patients with opacities such as cataract.
- 90° mosaic: seven internal fixation points, controlled from the tablet, let the camera build a mosaic up to 90° horizontally.
- Comfortable positioning: a forehead design without a chinrest limits stray light and lets the patient talk without moving the eyes.
Delegation ready workflow
The interface makes it easy to set up a screening and check image quality before saving. Software tools include red-free and deep layer filters, automatic mosaic, cup-to-disc ratio and a shared folder. Multilevel user accounts record and summarise each patient’s results, and a direct connection to a standard DICOM server allows review elsewhere in the practice. An automatic PDF report combines images, practitioner notes and patient education content. Secure data transmission also supports remote reading by a licensed specialist, where such services are available.
Specifications
Hardware
| Capture | Auto shoot and auto focus |
|---|---|
| Field of view | 45 ° |
| Mosaic field | Up to 90 horizontal ° |
| Retinal resolution | 14 µm |
| Minimum pupil size | 2.5 mm |
| Image resolution | 5 MP (2448 x 2051) |
| Fixation | 7 internal fixation points |
Software
| Filters | Red-free, deep layer |
|---|---|
| Mosaic | Automatic mosaic function |
| Analysis | Cup-to-disc ratio |
| Connectivity | Shared folder, standard DICOM compatible |
| Reporting | Automatic PDF patient report |
System
| Tablet screen | 10.43 inch |
|---|---|
| Dimensions (D x W x H) | 430 x 340 x 460 mm |
| Weight | 13 kg |
Downloads
Does Retina 800 need dilation?
In most cases no. It images through pupils down to 2.5 mm. The practitioner decides when dilation is still needed.
Can support staff take the images?
Yes. Capture is fully automatic with auto focus and auto shoot, and needs minimal training.
Does it connect to practice software?
Retina 800 supports a direct connection to a standard DICOM server and a shared folder, and creates PDF patient reports.
